Top features

Weight

4 times lower compared with the weight of the concrete kiosk

Mobility

2/3 lower transport and handling costs compared with the concrete kiosk

Variability

use of transformer - dry / oil, components from various world manufacturers

Multiple use

repeated use saves costs compared to conventional transformer stations

Climatic resistance

use in all climatic conditions

Quick installation

storage in a place without demanding landscaping

List of all features

  • In accordance with European and International Standards
  • Prefabricated substation contains MV and LV switchgear panels with distribution transformer to provide comprehensive solution
  • Containerized by Containex products range
  • Ease of transportation and ready to relocate
  • Ready for installation and commissioning
  • Compact and robust design Equipped with high quality MV and LV equipments manufacturers (Schneider Electric, Siemens, ABB, etc.)
  • Wide range of factory designed options
  • Easy accessibility
  • Reliable and minimal maintenance
  • Reduce construction cost
  • Reduce transportation cost
  • Reduce inter-equipment cabling cost
  • Minimum space required for installation

Safety and reference standards

  • MV/LV transformer substations comply with European and International Standards
  • Monitoring & Control as standard feature
  • Protect operating personnel against atmosphere
  • MV Switchgear, LV switchgear and Distribution transformer are segregated by sheet steel partition
  • Easy to escape from fire accident
  • Provides high degree of protection against ingress of solid foreign objects
  • Fitted with mandatory safety interlocks
  • Complete sheet steel housing is readily earthed

Features of construction & Electrical features

Service and environmental conditions
Standard dimensions (ISO)
Electrical features - MV
Electrical features - LV

Service and environmental conditions

External temperature (min/max)
-20° ÷ +50 C°
Irradiation
500 w/m2
Maximum wind speed
140 km/h
Maximum snow load on the horizontal projection at 1000 m
220 Kg/m2
Severe seismic activity
AF 5
External Protection class
IP55

Standard dimensions (ISO)*

Container (feet)
10
15
20
Length (mm)
2991
4550
6058
Height (mm)
2438
2200
2438
Width (mm)
2591
2260
2591
*Other dimensions available on request.

Medium Voltage Switchgear Main Electrical Features

The MV/LV transformer substationis supplied with a cast resin transformer. Oil or air insulated transformers are also available on request. The transformer installed may be from 100kVA to 2500kVA.
Rated voltage
12 kV
17,5 kV
25 kV
Power frequency withstand voltage (50-60 Hz 1 min.) towards the ground and between phases
28 kV / 32 kV
38 kV / 45 kV
50 kV / 60 kV
Rated lightning impulse withstand voltage towards the ground and between phases
75 kV / 85 kV
95 kV / 105 kV
125 kV / 145 kV
Rated current
400-630 A
Short time withstand current 1 sec on main circuits and earth circuits
400-630 A
Internal arc withstand 1 sec
12,5-21 kA

L.V. Switchgear Main Electrical Features

The MV/LV transformer substationis supplied with a cast resin transformer. Oil or air insulated transformers are also available on request. The transformer installed may be from 100kVA to 2500kVA.
Rated voltage up to
400 - 1000 V
Rated current
up to 3200 A
Rated short circuit current
75 kA
Rated short-term withstand current
75 kA
Rated peak withstand current
125 kA
Rated impulse voltage
8 kV
Rated frequency
50-60Hz

Fittings & Accessories

Accessory electrical equipment

  • Monitoring & Control for MV and LV equipments
  • Utility measuremend box (internal or external)
  • Fixed PFC
  • Automatic PFC (optional)
  • UPS (Uninterruptable Power Supply)
  • Fire detection and extinguishing (optional)

Internal accessories and auxiliary installations

  • Lighting installation with electric switch
  • Interlocked socket 230 Volt - 16A
  • HVAC (optional)
  • Accident prevention accessories: powder extinguisher, recharging emergency lighting, insulated carpet, warning notice, substation electrical drawing

External cabinet accessories

  • Flashing warning light (IP55)
  • Emergency pushbutton under glass
